Injen Front Mount Intercooler - FM9200i

FM9200i
2015-2023 Ford Mustang L4-2.3L EcoBoost
Limited Supply
Availability: Orders may take up to 30 days to deliver
Pricing: $600.95

Qty:
Free Ground Shipping on orders over $200.00- 48 continental states

Description

The 2015-2023 Mustang 2.3L Ecoboost is a great platform for soaking up highway miles during the weekday and tearing it up at the track on the weekend. With some minor modifications, the 2.3L Turbo engine is capable of producing some killer power. Added power will push the limits of the stock charge air system, necessitating an upgrade for the stock tube-and-fin intercooler, which is prone to heat soak. Injen has developed a highly efficient bar-and-plate intercooler engineered specifically to fit the 2015-2023 Ford Mustang 2.3L Ecoboost.

The FM9200i intercooler is a direct-fit unit and features a huge increase in core volume while requiring no modification to your Mustang. This cooler is constructed with cast end tanks and precision CNC-machined aluminum flanges for use with the factory intercooler piping or Injen’s aftermarket charge pipes (sold separately). The Injen Ford Mustang intercooler reduces intake temperatures by 50 degreeF and provides an increase of up to 17 HP and 17 Lbs. of torque while retaining factory boost pressure across the core.

This Mustang 2.3L Turbo intercooler also features precision TIG-welding and has a unique silver finish that is reminiscent of brushed aluminum. With an installation time of one-hour, great power and temperature benefits, and a Lifetime Warranty, the Injen FM9200i intercooler is a must-do upgrade for any stock or modified Mustang 2.3L Ecoboost.

Prop 65 Compliance

This product can expose you to chemicals including Chromium, Nickel, Carbon Black, Bisphenol A/Epichclorohydrin Polmer & Cobalt, which are known to the State of California to cause cancer, and (Antimony [Oxide], Arsenic, Beryllium. Chromium (hexavalent), Cobalt Cadmium, Lead, and Nickel which is known to the State of California to cause birth defects or other reproductive harm.

Warranty

SES Intercooler and exhaust systems that have been installed will not be eligible for return under any circumstances. Injen Technology offers a Limited Lifetime Warranty to the original purchaser against defects in material and workmanship. Injen Technology will replace, at no charge, any Injen product considered by Injen Technology to be defective. Any and all warranty coverage is limited to the repair or replacement of the defective part only, at Injen Technology’s discretion. Proof of purchase is required. The warranty does not cover incidental or consequential damages, damages caused from improper installation, nor does it cover the cost of installation or removal of the defective part or its replacement. All warranty items must be sent freight prepaid with a valid RMA (Return Merchandise Authorization) number and copy of original invoice. Most exhaust and Intercooler system installations may require a lift and or specialized tools. Due to the installation complexity of automotive exhaust and Intercooler systems, Injen Technology recommends that a qualified technician perform the installation. Most local Tuner or exhaust and muffler shops offer professional installation.

Key Features

  • Direct fit for the 2015-2023 Ford Mustang L4-2.3L Ecoboost
  • Dyno Proven gains of up to 17 hp and 17 lb-ft. of torque
  • Outlet temperature up to 50º lower than stock intercooler
  • TIG-welded Aluminum Bar-Plate
  • Stock Pressure Drop Retained within 0.5 psi
  • Designed to work with stock calibration
  • Increases throttle response and decreases turbo lag
  • Uses all factory mounting locations
  • Includes all necessary hardware for a hassle-free installation
  • Note: This product is not CARB exempt at this time and is not legal for sale in California or use on vehicles registered with the California Department of Motor Vehicles.

Details

  • FM9200i
  • FM9200i
  • 843115021153
  • Injen Technology
  • Orders may take up to 30 days to deliver
  • New

Categories

Shipping Information

  • Item Requires Shipping
  • 27.0 lbs.
  • W13.0000” x H17.0000” x L34.0000”
  • Free Ground Shipping on orders over $200.00- 48 continental states
