Injen Front Mount Intercooler - FM1582i

FM1582i
2017-2019 Honda Civic Type R L4-2.0L Turbo
Pricing: $592.75
Qty:
Free Ground Shipping on orders over $200.00- 48 continental states

Description

The all new Type-R Civic (FK8) is a great platform for soaking up highway miles during the weekday and tearing it up at the track on the weekend! With some minor modifications, the 2.0L Turbo engine is capable of producing some gnarly power. But, the added power of some tuning and bolt-ons will push the limits of the stock charge air system, necessitating an upgrade for the stock tube-and-fin intercooler, which is prone to heat soak. Thankfully Injen has developed a highly efficient bar-and-plate intercooler engineered specifically to fit the Type-R Civic.

The FM1582i intercooler is a direct-fit unit and features a 25% increase in core volume while requiring no modification to your civic. This cooler is constructed with cast end tanks and precision CNC-machined aluminum flanges for use with the factory intercooler piping. The Injen Honda Civic Type-R intercooler reduces intake temperatures by 30F and provides an increase of up to 27 HP and 23 Ft. Lbs. of torque while retaining factory boost pressure across the core.

This Civic Type-R 2.0L turbo intercooler also features precision TIG-welding and has a unique silver finish that is reminiscent of brushed aluminum. With a one-hour installation, great power, temperature benefits, and a Lifetime Warranty, the Injen FM1582i intercooler is a must-do upgrade for any stock or modified Civic type-R.

Notes

No piping included. Optional intercooler piping kit available. Part # SES1582ICP

Key Features

Direct Fit for the 2017-2019 Honda Civic Type R L4-2.0L Turbo
Dyno Proven gains of up to 27 hp and 23 lb-ft. of torque
100% Direct bolt-on front mount intercooler
No piping included.
Optional intercooler piping kit available. P/N# SES1582ICP
CAD designed end tanks for optimal air flow.
Intercooler core dimensions 21.06 x 5.750 x 5.28
Designed to work with the stock calibration
Optional intercooler piping kit available. Part # SES1582ICP
Made in Pomona California, USA
Injen Technology Limited Lifetime Warranty

Prop 65 Compliance

This product can expose you to chemicals including (Antimony [Oxide], Arsenic, Beryllium. Chromium (hexavalent), Cobalt Cadmium, Lead, and Nickel which is known to the State of California to cause birth defects or other reproductive harm.

Warranty

SES Intercooler and exhaust systems that have been installed will not be eligible for return under any circumstances. Injen Technology offers a Limited Lifetime Warranty to the original purchaser against defects in material and workmanship. Injen Technology will replace, at no charge, any Injen product considered by Injen Technology to be defective. Any and all warranty coverage is limited to the repair or replacement of the defective part only, at Injen Technology’s discretion. Proof of purchase is required. The warranty does not cover incidental or consequential damages, damages caused from improper installation, nor does it cover the cost of installation or removal of the defective part or its replacement. All warranty items must be sent freight prepaid with a valid RMA (Return Merchandise Authorization) number and copy of original invoice. Most exhaust and Intercooler system installations may require a lift and or specialized tools. Due to the installation complexity of automotive exhaust and Intercooler systems, Injen Technology recommends that a qualified technician perform the installation. Most local Tuner or exhaust and muffler shops offer professional installation.

Details

  • FM1582i
  • FM1582i
  • 843115023010
  • Injen Technology
  • New

Categories

Shipping Information

  • Item Requires Shipping
  • 36.0 lbs.
  • W11.0000” x H11.0000” x L41.0000”
  • Free Ground Shipping on orders over $200.00- 48 continental states
